Build Kit
Frameset
-
Frame
Journeyman 24 Aluminum
-
Color
Red
-
Fork
Journeyman 24 Aluminum
-
Rear Shock
N/A
Components
-
Headset
FSA ZS-4
-
Seatpost
Promax
-
Stem
Promax
-
Grips/Bar Tape
Cork Bar Tape
-
Saddle
Velo
-
Handlebar
Salsa Cowbell
Drivetrain
-
Front Derailleur
N/A
-
Rear Derailleur
microSHIFT ADVENT M6195M
-
Cassette
microSHIFT ADVENT H093, 11–42t, 9-speed
-
Chain
KMC X9
-
Crankset
Samox, 3 piece square taper, 36t with chainguard
-
Shifter
microSHIFT ADVENT M090
-
Brake Calipers
Promax DSK-300R
-
Rotors
160 mm rotors
Wheels
-
Front Wheel
Novatec 100 mm QR hub, WTB ST i23 TCS 2.0 32h rim
-
Rear Wheel
Novatec 135 mm QR hub, WTB ST i23 TCS 2.0 32h rim
-
Front Tire
Teravail Sparwood, 24 x 1.85"
-
Rear Tire
Teravail Sparwood, 24 x 1.85"
Weight
-
Complete Bike
23 lbs
*Specifications are subject to change without notice
Geometry
| Size | One Size |
|---|---|
| A. Effective Top Tube | 455.0 |
| B. Stand Over | 609.0 |
| C. Reach | 342.0 |
| D. Stack | 436.9 |
| E. Total Seat Tube Length | 350.0 |
| F. Headtube Length | 90.0 |
| G. Headtube Angle |
69.0
|
| H. Seat Tube Angle |
75.5
|
| I. BB Drop | 33.0 |
| K. Chainstay Length | 390.0 |
| L. Fork Length Axle to Crown | 354.0 |
| M. Fork Offset | 33.0 |
| N. Wheelbase | 928.5 |
| Crank Arm Length | 45.0 |
| Handlebar Width | |
| Recommended Rider Height | 140.0 - 157.0 |
| Stem Length | 38.0 |
Measurements based on:
a 24 x 1.85" tire measuring 603 mm in diameter
Frame Specs
- Design Wheel/Tire Sizes 24 x 1.85" (24 x 2.0" Max)
- Suspension Fork Length (Travel) N/A
- Rigid Fork Length 354 mm
- Fork Offset 40 mm
- Rear Spacing 135 mm QR
- Rear Brake (Rotor) Flat Mount 140 mm (160 mm max)
- Front Brake (Rotor) 51 mm I.S. Mount (160 mm)
- Headset - Upper ZS44/28.6
- Headset - Lower ZS44/30.0
- Front Spacing 100 mm QR
- Seatpost 27.2 mm
- Dropper Post Compatible No
- Seatpost Clamp 32.0 mm
- Front Derailleur Type Clamp-on (32.0 mm), bottom-pull
- Derailluer Hanger Salsa Derailleur Hanger 959 (QBP #FS0100)
- Bottom Bracket 68 mm BSA, threaded
- Crankset (Max Ring) 1x crankset: 38t Max; 2x crankset: 50/34t Max
- Accessory Mounts Under Downtube Mount: Yes; Top Tube Mount: No; Front Rack Mount: No
- Bottle Mounts 1 in main triangle
- Fork Mounts Yes, one set of Three-Pack mounts on each fork leg
- Front Fender Mounts No
- Rear Fender Mounts No
